| 型号 | 内径 mm | 外径 mm | 最大工作压力 MPa | 最小爆破压力 MPa | 包装长度 m |
| H0815D | 8.2 | 15.2 | 3.5 | 14.7 | 100 |
| H1018C | 10.3 | 18.5 | 3.5 | 14.7 | 100 |
| H1119B | 11.2 | 19.5 | 3.5 | 14.7 | 100 |
| H1320C | 13.1 | 20.2 | 3.5 | 14.7 | 100 |
| H1623C | 15.8 | 23.5 | 3.5 | 12 | 100 |
| H1928B | 19 | 28 | 1.5 | 12 | 50 |
| H2232G | 22.2 | 32 | 3.5 | 12 | 50 |
| H2839A | 28 | 39 | 1.5 | 12 | 50 |
